Design 1715 - Puffin II


This is the second Puffin designed and built for Edward Greef. She was built by American Marine Ltd. of Hong Kong of local woods such as ipol, yacal and teak and launched in 1963.

Here is the general arrangement plan.


Here's a peek at her shape.


And finally here's an article about her. Please double click for zoom.


Principal Dimensions
LOA 39'-10"
LWL 27'-10"
Beam 10'-7"
Draft 6'-0"
Displacement 20,670 lbs
Ballast 7,300 lbs
Sail Area 778 sq ft
